Custom 12-Step Ceramic Calibration Block — High-Precision to Customer Drawing
Industrial ceramic stepped gauge with 12 reference levels and 4 mounting holes.
Manufactured to customer’s drawing with ±0.002mm step tolerance.
Fixed-mount design for consistent, repeatable measurement.
Share
Custom 12-Step Ceramic Calibration Block — High-Precision to Customer Drawing
The Challenge
Customer provided a detailed drawing: a multi-step ceramic gauge with 12 reference levels and four mounting holes. Required tolerance: ±0.002mm per step — a demanding specification that required careful material selection and precision grinding.
What We Built
  • 12-step industrial ceramic calibration block
  • Four corner mounting holes for fixed installation
  • Each step ground to ±0.002mm tolerance, verified and documented
Meeting High-Precision Requirements
±0.002mm (±2μm) across 12 steps on a single ceramic block is tight. We controlled every variable — material selection, grinding process, temperature during machining — to ensure each step hit the customer’s tolerance. Full measurement data provided with delivery.
Applications
  • Precision height reference standard — multi-level reference in one block
  • Sensor calibration across multiple reference points
  • Machine vision and optical system height verification
  • Laboratory metrology reference
  • Production line inspection — fixed-mount for consistent, repeatable results
Why Ceramic + Mounting Holes
  • 12 reference heights in one compact block — replaces multiple individual standards
  • Mounting holes allow fixed installation — eliminates handling variation, improves repeatability
  • Ceramic: no corrosion at mounting points, no thermal drift, long-term stability
  • Fixed-mount setup is ideal for automated or semi-automated inspection workflows
Your Design, Our Precision
Have a drawing with tight tolerances? We’ll manufacture it to your exact specs and provide actual measurement results — so you can verify before you use it.
Notes: The foregoing information has been desensitized for presentation. Should your company have commercial confidentiality requirements, our company may enter into a special confidentiality agreement with you.
